HUPO-PSI Recommendation · Working Draft

File Format Specification

An open, columnar, random-access file format for storing mass spectra, chromatograms, and rich instrument metadata — designed to succeed mzML for modern, large-scale mass spectrometry.

Status: Draft Version 0.9 · Draft 5 Built on Apache Parquet CC-BY-ND 4.0

This is a working draft

This document is a DRAFT under active revision and has not yet been ratified through the HUPO-PSI Document Process. Content, schemas, and controlled-vocabulary terms may change. Feedback is explicitly solicited — please open an issue.

Abstract

mzPeak is an open, next-generation file format for mass spectrometry data. Advances in MS instrumentation — higher resolution, faster scan rates, greater sensitivity, and the growing use of ion mobility and imaging — have sharply increased the volume and dimensionality of the data produced in proteomics, metabolomics, and lipidomics. Established open formats such as mzML and imzML increasingly struggle with the resulting file sizes, data-access patterns, and metadata demands, while vendor-specific formats offer faster access at the cost of interoperability and long-term archival stability. mzPeak is designed to address these needs as a community standard; the motivation and design rationale are set out in the accompanying white paper (1).

The format takes a hybrid approach: an archive of Apache Parquet tables — packaged in an uncompressed ZIP container, or an unpacked directory, together with a small JSON index — that stores numerical signal data as compact, columnar binary while keeping metadata both human- and machine-readable and anchored in the PSI-MS controlled vocabulary. Building on the widely available Apache Parquet and Apache Arrow libraries rather than a single core implementation, the on-disk structure is language-independent. Uncompressed archive members and a required Parquet page index let a reader locate and decode a single spectrum without parsing an entire run, the basis for random access from local disk, object storage, or over HTTP. This document specifies that format: its container, signal-data layouts, index file, and metadata model.

What you'll find here

  • Introduction

    Why mzPeak exists, what problems it solves, and a high-level tour of an archive.

    Overview & motivation

  • Foundations

    A short Parquet primer and how multiple Parquet files are bundled into one archive.

    Parquet & containers

  • Data Layouts

    Packed metadata tables, the array index, and the point & chunked signal layouts.

    Layouts

  • Archive Organization

    The mzpeak_index.json file, data kinds, and entity types that organise a run.

    The index file

  • File Schemas

    Concrete column-level schemas for spectra, chromatograms, and wavelength spectra.

    Schemas

  • Implementations

    The read/write libraries — Rust, Python, R, C#, and JavaScript/TypeScript.

    Implementations

  • Tools

    Converters, the conformance validator, browser viewers, and example data.

    Tools

  • Reference

    Glossary, bibliography, authorship, and the intellectual-property statement.

    Reference

Anatomy of an archive

An mzPeak archive (.mzpeak) is a small set of named files:

File Contents
mzpeak_index.json Manifest describing every file in the archive by entity type and data kind.
spectra_metadata.parquet Spectrum-level and file-level metadata (descriptions, scans, precursors, selected ions).
spectra_data.parquet Spectrum profile signal data, in point or chunked layout.
spectra_peaks.parquet (optional) Spectrum centroid signal, stored separately from profile data.
chromatograms_metadata.parquet Chromatogram-level and file-level metadata.
chromatograms_data.parquet Chromatogram signal data, in point or chunked layout.

Additional Parquet files may be added to cover further modalities (for example wavelength spectra) as the format grows.

Reference implementations

mzPeak is backed by five independent, from-scratch implementations (not bindings to a single core):

  • Rust — read/write reference implementation · HUPO-PSI/mzPeak
  • Python — read-only, zero-copy Arrow/Pandas API
  • R — read-only, dplyr-compatible access
  • C# — read/write · HUPO-PSI/mzPeak.NET
  • JavaScript / TypeScript — read-only, runs in the browser, Node, and Deno · online viewer

See Implementations for details, and Tools for converters, the conformance validator, and viewers.

Status of this document

This document provides information to the proteomics community about the mzPeak file format. Distribution is unlimited. It will be ratified via the HUPO Proteomics Standards Initiative (PSI) Document Process, and any alterations MUST also follow the HUPO-PSI Document Process.

Version: Draft 5 of version 0.9
